Electric Tri-eccentric Metal Butterfly Valve

2025-06-25

The electric tri-eccentric metal Butterfly Valve is a highly efficient flow control device, integrating advanced electric actuation with an innovative tri-eccentric structure. Driven by an electric motor, it enables automated and precise control, making it ideal for industrial processes requiring accuracy and reliability.

The valve's tri-eccentric design—offset centers of the disc axis, seat axis, and rotation axis—creates a unique sealing mechanism. This geometry allows the metal disc to make contact with the metal seat only when fully closed, minimizing friction during operation and extending the valve's lifespan. The metal-to-metal sealing ensures zero leakage, high-temperature resistance (up to 600°C), and excellent performance under high pressure, making it suitable for handling abrasive, corrosive, or high-viscosity media.

With its quick 90-degree rotation for full opening or closing, the valve offers rapid response and low torque operation. It is widely applied in industries such as petrochemicals, power generation, and metallurgy, where strict flow control and harsh operating conditions are common. The combination of electric actuation's flexibility and the tri-eccentric structure's durability makes this valve a reliable choice for modern industrial systems.
