Products
Brand: cepai
Support Customization: Oem
Place Of Origin: China
Medium Temperature: Normal Temperature
Power: Electric, Manual
Flow Medium: Gas, Water, Oil
Structure: Control
Packaging: Box
Transportation: Ocean,Land,Air,Express,others
Port: Shanghai,Ningbo,Huaian
Payment Type: D/P,T/T,L/C
| Working Pressure | 5000 Psi ~ 15,000 Psi |
| Flange Specification | 11〞～20-3/4〞（46mm～230mm） |
| Working Temperature | -60°C ~ 121°C (KU grade) |
| Material Classes | AA, BB, CC, DD, EE, FF, HH |
| Specification Levels | PSL1 ~ PSL4 |
| Performance Levels | PR1 ~ PR2 |
| Working Medi | Oil, natural gas, mud, media containing H₂S and CO₂ gases |
· Flange connection
· Coupling (clamp) connection
· Threaded connection
Core Functions:
· Secure the drilled wellhead and connect wellhead casing strings.
· Seal and control the casing annulus, suspend tubing strings, and regulate wellhead pressure and flow.
· Channel oil to export pipelines and close the well when necessary. Suitable for acid fracturing, water injection, and testing operations.
Application Flexibility:
· Compatible with various casing and tubing programs and connection types, adapting to diverse well construction requirements.
· Equipped with pneumatic/hydraulic safety valves upon customer request to enhance emergency shutdown capabilities.
Corrosion & Pressure Resistance:
· Material classes (AA~HH) and hardfaced sealing surfaces (as implied by industry standards) ensure resistance to H₂S, CO₂, and other corrosive media, meeting harsh oilfield environments.
· High-pressure rating (up to 15,000 Psi) supports operations in deep wells, high-pressure gas fields, and offshore platforms.
Operational Safety:
· Multiple connection types (flange/coupling/threaded) provide leak-proof sealing and facilitate rapid installation/removal.
· Integral design reduces potential leakage points, enhancing well control safety during acid fracturing and high-pressure operations.
Product Categories : API Series > API 6A
